Laboratory Equipment KD 400 Drying Oven KD 400

375 Litres medium size drying oven
SKU: KD 400
Manufacturer: Nuve
Pack Size: 1



KD series ovens are the instruments of choice for routine heating and drying. With their large capacity, they are an excellent investment for the capacity. The stainless steel interior of KD 200 and KD 400 are resistant to many chemicals.

Proportional, integral, differential temperature control keeps the oven on target and N-Prime™ microprocessor-based system offers a variety of alarms. An independent safety thermostat ensures no overshoot in case of any failure.

Large, dual displays with large, bright characters, allow the actual temperature and time values to be seen from across the laboratory.

Gross Volume: 398
Net Volume: 371 liters
Temperature range: 70°C to 250°C
Interior chamber: Stainless steel
2 circulation fans
N-Prime™ programmable PID microprocessor control system
Easy programming with one button, just turn and push
Large bright digital display for temperature and time
Password protected menu to secure the operation
Programmable alarm limits
Internal memory up to 125 days
Data recording on memory stick by means of USB port
Timer: 1 minute to 100 hours and hold position
Delayed start timer: 1 min. to 99,9 hours
Air forced ventilation
Adjustable extraction fan
Adjustable safety thermostat
Two shelves
Chamber dim. (WxDxH): 500x590x1350 mm
Int. dim. (WxDxH): 500x550x1350 mm
Ext. dim. (WxDxH): 684x780x1620 mm
400 V - 50/60 Hz, 3 phases+N+G



 FACTORY FITTED OPTION
KD XXX WFWi-Fi connection for N-Mobile™
 ACCESSORIES
R 01 111Mesh type shelf for KD 200
R 01 134Mesh type shelf for KD 400
K 23 040Shelf carrier for KD 200 / KD 400



KD 400 Brochure Download:


Attribute nameAttribute value
Pack Size1
Capacity371L
Temperature Max250 °C
Temperature Min70°C
